Fiat
Fiat Palio Punto 908581 46527330 1.9D 188A3.000 Cylinder Head
- Engine:188A3.000
- Displacement: 1.9D
- OE NO.:46527330
- OE NO.: 908581
- Product description: Applications: * Renault Avantime 1 (D66) in 2002 – 2003; * Renault Espace 3 (J66) in 2000 – 2002; Espace 4 (J81) in 2002 – 2007; * Renault Laguna 2 (X74) in 2002 – 2007; * Renault Master 2 (X70)
|
Engine Code |
188A3.000 |
|
Displacement |
1.9D |
|
Cylinder Number |
4 Cylinder |
|
MOQ |
1 Pcs |
|
Quality |
100% Tested |
|
Condition |
100% New |
|
Certification |
TS16949,ISO9001 |
|
Warranty |
1Year/30,000Km |
The cylinder head with reference numbers 908581 and 46527330 is designed for Fiat 188A3.000 1.9L naturally aspirated diesel engines. This precision-engineered component features aluminum alloy construction with SOHC 8-valve configuration, compatible with Fiat Palio, Punto, Siena, and Strada models. The cylinder head delivers reliable sealing, efficient heat dissipation, and durable performance for urban commuting and daily driving.
Technical Features:
-
Reference Numbers: 908581 / 46527330
-
Type: Cylinder Head (Bare)
-
Valve Configuration: SOHC 8-Valve (2 valves per cylinder)
-
Material: Aluminum Alloy
-
Application: 188A3.000 1.9L Naturally Aspirated Diesel Engine
Engine Parameters:
-
Engine Code: 188A3.000 / 188A2.000 (1.9D family)
-
Displacement: 1.9 L (1,910 cc)
-
Configuration: Inline-4 SOHC, Naturally Aspirated Diesel
-
Power Output: 44-47 kW (60-64 HP) @ 4500 RPM
-
Torque: 110-120 Nm @ 2500 RPM
-
Fuel System: Indirect Injection (IDI) / Distributor Pump
-
Compression Ratio: 21.0:1
-
Bore × Stroke: 82 mm × 90 mm
-
Firing Order: 1-3-4-2
-
Emission Standard: Euro 2 / Euro 3
Suitable Models:
-
Fiat Palio (1996-2011, select markets)
-
Fiat Punto Mk2 / Mk2B (1999-2010)
-
Fiat Siena / Albea
-
Fiat Strada Pickup (1.9D variants)
-
Fiat Fiorino / Qubo (early diesel models)
The cylinder head with reference numbers 908581 and 46527330 is designed for Fiat 188A3.000 1.9L naturally aspirated diesel engines. This precision-engineered component features aluminum alloy construction with SOHC 8-valve configuration, compatible with Fiat Palio, Punto, Siena, and Strada models. The cylinder head delivers reliable sealing, efficient heat dissipation, and durable performance for urban commuting and daily driving.
Technical Features:
- Reference Numbers: 908581 / 46527330
- Type: Cylinder Head (Bare)
- Valve Configuration: SOHC 8-Valve (2 valves per cylinder)
- Material: Aluminum Alloy
- Application: 188A3.000 1.9L Naturally Aspirated Diesel Engine
Engine Parameters:
- Engine Code: 188A3.000 / 188A2.000 (1.9D family)
- Displacement: 1.9 L (1,910 cc)
- Configuration: Inline-4 SOHC, Naturally Aspirated Diesel
- Power Output: 44-47 kW (60-64 HP) @ 4500 RPM
- Torque: 110-120 Nm @ 2500 RPM
- Fuel System: Indirect Injection (IDI) / Distributor Pump
- Compression Ratio: 21.0:1
- Bore × Stroke: 82 mm × 90 mm
- Firing Order: 1-3-4-2
- Emission Standard: Euro 2 / Euro 3
Suitable Models:
- Fiat Palio (1996-2011, select markets)
- Fiat Punto Mk2 / Mk2B (1999-2010)
- Fiat Siena / Albea
- Fiat Strada Pickup (1.9D variants)
- Fiat Fiorino / Qubo (early diesel models)
