The cylinder head designed for Chery SQRE4T15B 1.5L turbocharged gasoline engines. This aluminum alloy cylinder head features DOHC 16-valve configuration with direct injection and variable valve timing (VVT) compatibility, delivering reliable performance for Chery Tiggo 8, Karry K60, Arrizo series, and related compact vehicle platforms.

---

Quick Specifications:

• Engine Code: SQRE4T15B / E4T15B (Chery Acteco Turbo Family)
• Displacement: 1.5 L (1,498 cc)
• Configuration: Inline-4 DOHC 16V, Turbocharged & Intercooled
• Fuel System: Direct Injection (GDI) / MPI + VVT + Turbo
• Material: Aluminum Alloy
• Valve Configuration: DOHC 16-Valve (4 valves per cylinder)
• Cooling: Water-cooled with integrated exhaust manifold (select variants)

---

Performance Data:

• Power Output: 108-115 kW (147-156 HP) @ 5,500 RPM
• Torque: 210-230 Nm @ 1,750-4,000 RPM
• Compression Ratio: 9.5:1 - 10.0:1 (turbo-optimized)
• Emission Standard: Euro 5 / Euro 6 / China VI

---

Applications:

• Chery Tiggo 8 / Tiggo 8 Pro (2018-present, 1.5T variants)
• Karry K60 / K60S (1.5T SQRE4T15B variants)
• Chery Arrizo 5 GX / Arrizo GX (1.5T variants)
• Chery Tiggo 7 / Tiggo 7 Pro (select 1.5T applications)
• Chery Exeed TX / LX (entry-level 1.5T variants)
• Aftermarket engine rebuild & replacement projects
